番茄自然群体磷利用效率分析及耐低磷种质筛选

doi:10.16420/j.issn.0513-353x.2023-0053

摘要/Abstract

摘要：

以蛭石为基质，通过营养液控制，在幼苗期对包括196份材料的番茄自然群体进行了正常磷浓度及其10%和1%（830、83和8.3 μmol · L^-1 HPO₄^2-）磷水平处理，并以幼苗地上部干、鲜质量、株高和叶绿素含量等指标为依据，对该自然群体进行了磷效率评估和耐低磷材料筛选。研究结果表明，地上部鲜质量和干质量在所检测指标中变异较大，材料间存在丰富的遗传变异。以低磷处理地上部鲜质量、干质量与正常磷处理的比值作为耐低磷评价指标，通过聚类分析，分别获得了1%磷水平下3个耐低磷番茄材料TS-653、yf4和pl1，和10%磷水平下3个耐低磷番茄材料TS-26、TS-643和TS-653，并分析了它们的相对磷含量以及地上部和地下部的磷含量比值。利用模糊隶属函数法计算各材料的磷效率综合值，基于散点图，筛选出在3个磷水平下均表现为高效的番茄种质TS-614。

关键词: 番茄, 种质资源, 耐低磷, 磷高效, 磷效率综合值

Abstract:

A natural population of tomato containing 196 accessions was treated with three levels of phosphorus including full nutrition（P，830 μmol · L^-1 HPO₄^2-），1% P（8.3 μmol · L^-1 HPO₄^2-）and 10% P（83 μmol · L^-1 HPO₄^2-）by nutrient solution at seedling stage using vermiculite as substrate. This natural population was evaluated for phosphorus efficiency and screened for low phosphorus tolerant accessions based on shoot dry weight，shoot fresh weight，plant height and chlorophyll content of seedlings. The results showed that both fresh and dry weights of the shoots exhibited a vast variation among the investigated indexes，indicating abundant genetic variation among these accessions. Using fresh weight ratio and dry weight ratio of shoot as evaluation indexes for low phosphorus tolerance，three accessions with low phosphorus tolerance at 1% P（TS-653，yf4 and pl1）and 10% P（TS-26，TS-643 and TS-653）were screened out，respectively，by cluster analysis，and the relative phosphorus contents as well as the ratios of shoot phosphorus contents to root phosphorus contents of these accessions were also analyzed. Phosphorus efficiency comprehensive value of all the accessions was calculated using the fuzzy membership function method. Based on scatter plots，the accession TS-614 was selected，which showed high efficiency under three phosphorus levels.

Key words: tomato, germplasm, low phosphorus tolerance, high phosphorus efficiency, phosphorus efficiency comprehensive value

李品, 甘宁, 陈家伟, 项思翔, 沈静漪, 欧阳波, 卢永恩. 番茄自然群体磷利用效率分析及耐低磷种质筛选[J]. 园艺学报, 2024, 51(5): 993-1004.

LI Pin, GAN Ning, CHEN Jiawei, XIANG Sixiang, SHEN Jingyi, OUYANG Bo, LU Yong’en. Analysis of Phosphorus Utilization Efficiency in Natural Population of Tomato and Screening of Low Phosphorus Tolerant Germplasm[J]. Acta Horticulturae Sinica, 2024, 51(5): 993-1004.

图/表 9

参考文献 26

[1]	Bao Shi-dan. 2000. Agrochemical analysis of soil. Beijing: China Agriculture Press. (in Chinese)
	鲍士旦. 2000. 土壤农化分析. 北京: 中国农业出版社.
[2]	Bai Dong-yin, Feng Guo-hua, Zhang Hui-yun, Chen Rong-zhen, Wang Xiao-jun. 2007. Screening of phosphorus efficient wheat genotypes under low phosphorus stress. Journal of Wheat Crops, 27 (3):407-410,415. (in Chinese)
	柏栋阴, 冯国华, 张会云, 陈荣振, 王晓军. 2007. 低磷胁迫下磷高效基因型小麦的筛选. 麦类作物学报, 27 (3):407-410,415.
[3]	Cao Jing, Zhang Fu-suo. 2000. Effects of different genotypes of wheat seedlings on phosphorus uptake and utilization efficiency and water content under low phosphorus conditions. Journal of Plant Ecology, 24 (6):731-735. (in Chinese)
	曹靖, 张福锁. 2000. 低磷条件下不同基因型小麦幼苗对磷的吸收和利用效率及水分的影响. 植物生态学报, 24 (6):731-735.
[4]	Chandrasekaran M, Boopathi T, Manivannan P. 2021. Comprehensive assessment of ameliorative effects of AMF in alleviating abiotic stress in tomato plants. Journal of Fungi(Basel), 7 (4):303.
[5]	Chen Yan-ling, Wang Ning, Shi Lei. 2023. Analysis of phosphorus efficiency in natural populations of Brassica napus at seedling stage and screening of excellent germplasm with high phosphorus efficiency. Oil Crop Science, 45 (1):56-62. (in Chinese)
	陈燕玲, 王宁, 石磊. 2023. 甘蓝型油菜自然群体苗期磷效率分析及磷高效优异种质筛选. 中国油料作物学报, 45 (1):56-62. doi: 10.19802/j.issn.1007-9084.2022087
[6]	Cui Ya-sheng, Zhang Ying. 2013. Tomato fertilization techniques. Northwest Horticulture(Vegetable),(2):46-47. (in Chinese)
	崔亚胜, 张颖. 2013. 番茄施肥技术. 西北园艺(蔬菜),(2):46-47.
[7]	Fohse D, Classen N, Jungk A. 1988. Phosphorus efficiency of plants:1. External and internal requirement and P uptake efficiency of different plant species. Plant and Soil, 110 (1):101-109.
[8]	Gong Si-yu. 2019. Screening of low-phosphorus tolerance genotypes in tobacco seedlings and study on their physiological mechanisms[M. D. Dissertation]. Nanchang: Jiangxi Agricultural University. (in Chinese)
	龚丝雨. 2019. 烟草苗期耐低磷基因型筛选及生理机制研究[硕士论文]. 南昌: 江西农业大学.
[9]	Guo Zai-hua, He Li-yuan, Xu Cai-guo, Zhang Qi-fa. 2005. Screening and identification of low phosphorus tolerant germplasm resources of rice index. Acta Agronomica Sinica, 31 (1):65-69. (in Chinese)
	郭再华, 贺立源, 徐才国, 张启发. 2005. 水稻耐低磷种质资源的筛选、鉴定指标. 作物学报, 31 (1):65-69.
[10]	He Nan-nan. 2010. Screening of phosphorus-efficient sweet maize varieties and study on nutritional differences[M. D. Dissertation]. Zhanjiang: Guangdong Ocean University. (in Chinese)
	贺囡囡. 2010. 磷高效甜玉米品种筛选及营养差异性研究[硕士论文]. 湛江: 广东海洋大学.
[11]	Jia Ya-tao, Xie Sheng-jie, Niu Xu-long, Xing Guo-fang. 2017. Screening and identification of maize inbred lines with low phosphorus tolerance. Journal of Shanxi Agricultural University(Natural Science Edition), 37 (1):11-17. (in Chinese)
	贾亚涛, 谢圣杰, 牛旭龙, 邢国芳. 2017. 玉米耐低磷自交系的筛选与鉴定. 山西农业大学学报(自然科学版), 37 (1):11-17.
[12]	Li Zhi-dan, Han Rui-hong, Liao Gui-lan, Zhang Mei-hua. 2011. Comparative study on extraction methods of chlorophyll from plant leaves. Journal of Guangdong Second Normal University, 31 (3):80-83. (in Chinese)
	李志丹, 韩瑞宏, 廖桂兰, 张美华. 2011. 植物叶片中叶绿素提取方法的比较研究. 广东第二师范学院学报, 31 (3):80-83.
[13]	Li Zhi-gang. 2004. Screening of soybeans with different phosphorus efficiency genotypes and their reaction mechanism to phosphorus levels[Ph. D. Dissertation]. Shenyang: Shenyang Agricultural University. (in Chinese)
	李志刚. 2004. 不同磷效率基因型大豆的筛选及其对磷素水平的反应机理研究[博士论文]. 沈阳: 沈阳农业大学.
[14]	Liu Hai-xu, Wu Jun-jiang, Wang Jin-sheng, Lu Wen-cheng, Xu Peng-fei, Zhang Shu-zhen. 2017. Research progress on low phosphorus tolerance in soybeans. Soybean Science, 36 (4):639-644. (in Chinese)
	刘海旭, 吴俊江, 王金生, 鹿文成, 徐鹏飞, 张淑珍. 2017. 大豆耐低磷研究进展. 大豆科学, 36 (4):639-644.
[15]	Marques D J, da Silva E C, Siqueira J A C, Abedi E, Veloso F R, Maciel G M, Maluf W R. 2022. Variation in the dynamic of absorption and efficiency of phosphorus use in tomato. Scientific Reports, 12 (1):4379. doi: 10.1038/s41598-022-08337-3 pmid: 35288620
[16]	Urbanczyk-Wochniak E, Fernnie A R. 2005. Metabolic profiling reveals altered nitrogen nutrient regimes have diverse effects on the metabolism of hydroponically-grown tomato(SOLANUM LYCOPERSICUM)plants. Journal of Experimental Botany, 56 (410):309-321. doi: 10.1093/jxb/eri059 pmid: 15596475
[17]	Wan Yan-hui, Zhu Long-ying, Yang Zhi-jie, Zhu Wei-min. 2005. Effects of low phosphorus stress on seedling stage of different tomato genotypes. Journal of Agricultural Engineering, 21 (S2):57-59. (in Chinese)
	万延慧, 朱龙英, 杨志杰, 朱为民. 2005. 低磷胁迫对不同番茄基因型苗期影响的研究. 农业工程学报, 21 (S2):57-59.
[18]	Wang Hui-jun. 2010. Common symptoms of tomato deficiency and fertilization measures. China Horticulture Abstract, 26 (5):136. (in Chinese)
	王会君. 2010. 番茄常见的缺素症状及施肥措施. 中国园艺文摘, 26 (5):136.
[19]	Wang Jing, Han Xiao-ri, Gong Liang, Yin Hong-bin, Yu Cheng-guang. 2005. Study on physiological adaptability of roots of different tomato cultivars at seedling stage under low phosphorus stress. Journal of Shenyang Agricultural University, 36 (5):615-618. (in Chinese)
	王晶, 韩晓日, 宫亮, 阴红彬, 于成广. 2005. 低磷胁迫下不同番茄品种苗期根系生理适应性研究. 沈阳农业大学学报, 36 (5):615-618.
[20]	Wang Lan-zhen, Mi Guo-hua, Chen Fan-jun, Zhang Fu-suo. 2003. Identification of phosphorus nutrition efficiency of winter wheat varieties. Journal of China Agricultural University, 8 (5):69-73. (in Chinese)
	王兰珍, 米国华, 陈范骏, 张福锁. 2003. 冬小麦品种的磷营养效率鉴定. 中国农业大学学报, 8 (5):69-73.
[21]	Wang Mi. 2007. Study on the response of potato to phosphorus and the mechanism of different phosphorus efficiency[M. D. Dissertation]. Ya’an: Sichuan Agricultural University. (in Chinese)
	王谧. 2007. 马铃薯对磷素的响应及不同磷效率的机理研究[硕士论文]. 雅安: 四川农业大学.
[22]	Wang X R, Shen J B, Liao H. 2010. Acquisition or utilization,which is more critical for enhancing phosphorus efficiency in modern crops? Plant Science, 179 (4):302-306.
[23]	Wang Y H, Garvin D F, Kochian L V. 2001. Nitrate-induced genes in tomato roots,array analysis reveals novel genes that may play a role in nitrogen nutrition. Plant Physiology, 127 (1):345-358. doi: 10.1104/pp.127.1.345 pmid: 11553762
[24]	Yin Yuan-ping, Zhang Ya-qiong, Shen Yu-han, Zhao Zhi-yong, Xie Shi-qing, Yang Sheng-chao, Liang Quan. 2015. Screening of phosphorus efficient soybean genotypes using root morphology and configuration. Molecular Plant Breeding, 13 (5):999-1008. (in Chinese)
	尹元萍, 张雅琼, 申毓晗, 赵志勇, 谢世清, 杨生超, 梁泉. 2015. 利用根系形态构型筛选磷高效大豆基因型. 分子植物育种, 13 (5):999-1008.
[25]	Yu Xin-chao, Wang Jing, Zhu Mei-yu, Jiang Jing. 2015. Molecular mechanism of carbohydrate metabolism involved in tomato response to low phosphorus stress. Molecular Plant Breeding, 13 (12):2833-2842. (in Chinese)
	于新超, 王晶, 朱美玉, 姜晶. 2015. 碳水化合物代谢参与番茄响应低磷胁迫的分子机制. 分子植物育种, 13 (12):2833-2842.
[26]	Yuan Meng, Zhao Zheng-yan, Li Xue-lin, Zhang Fu-hou, Liu Feng-ju, Meng Chao-min. 2019. Differences in physiological and morphological responses of different genotypes of cotton under low phosphorus stress. Seed, 38 (4):20-23,30. (in Chinese)
	原梦, 赵峥艳, 李雪林, 张富厚, 刘逢举, 孟超敏. 2019. 低磷胁迫下不同基因型棉花生理和形态的响应差异. 种子, 38 (4):20-23,30.

处理 Treatment	地上部干质量/g Shoot dry weight			地上部鲜质量/g Shoot fresh weight			株高/cm Plant height
处理 Treatment	变幅 Range	均值 Average	变异系数 CV	变幅 Range	均值 Average	变异系数 CV	变幅 Range	均值 Average	变异系数 CV
正常磷 Normal P	0.07 ~ 5.51	1.10 ± 0.69 a	0.76	2.20 ~ 35.91	9.24 ± 6.43 a	0.65	14.00 ~ 63.00	32.60 ± 10.26 a	0.30
1%磷 1% P	0.06 ~ 0.91	0.40 ± 0.04 c	0.50	1.05 ~ 8.05	3.85 ± 1.52 b	0.38	8.67 ~ 37.33	19.50 ± 5.70 b	0.26
10%磷 10% P	0.11 ~ 2.92	0.64 ± 0.19 b	0.67	0.86 ~ 22.30	4.68 ± 3.38 b	0.66	8.00 ~ 48.00	20.00 ± 6.84 b	0.33
处理 Treatment	茎粗/mm Stem diameter			下胚轴长/cm Hypocotyl length			SPAD
处理 Treatment	变幅 Range	均值 Average	变异系数 CV	变幅 Range	均值 Average	变异系数CV	变幅 Range	均值 Average	变异系数CV
正常磷 Normal P	2.62 ~ 6.27	4.19 ± 0.49 a	0.17	1.50 ~ 10.80	5.13 ± 2.06 a	0.40	21.30 ~ 46.90	36.74 ± 4.86 a	0.14
1%磷 1% P	2.18 ~ 4.78	3.53 ± 0.26 c	0.14	1.00 ~ 7.80	3.64 ± 1.63 b	0.35	23.70 ~ 51.60	36.74 ± 5.35 a	0.14
10%磷 10% P	2.10 ~ 6.50	3.76 ± 0.49 b	0.19	1.50 ~ 11.50	5.50 ± 1.82 a	0.35	23.80 ~ 51.90	36.67 ± 5.83 a	0.16
处理 Treatment	叶绿素含量/（mg · L^-1）Chlorophyll content
处理 Treatment	变幅 Range	均值 Average	变异系数CV
正常磷 Normal P	0.04 ~ 0.15	0.09 ± 0.00 a	0.22
1%磷 1% P	0.01 ~ 0.07	0.03 ± 0.00 b	0.33
10%磷 10% P	0.03 ~ 0.17	0.09 ± 0.00 a	0.33

处理 Treatment	地上部干质量/g Shoot dry weight			地上部鲜质量/g Shoot fresh weight			株高/cm Plant height
处理 Treatment	变幅 Range	均值 Average	变异系数 CV	变幅 Range	均值 Average	变异系数 CV	变幅 Range	均值 Average	变异系数 CV
正常磷 Normal P	0.07 ~ 5.51	1.10 ± 0.69 a	0.76	2.20 ~ 35.91	9.24 ± 6.43 a	0.65	14.00 ~ 63.00	32.60 ± 10.26 a	0.30
1%磷 1% P	0.06 ~ 0.91	0.40 ± 0.04 c	0.50	1.05 ~ 8.05	3.85 ± 1.52 b	0.38	8.67 ~ 37.33	19.50 ± 5.70 b	0.26
10%磷 10% P	0.11 ~ 2.92	0.64 ± 0.19 b	0.67	0.86 ~ 22.30	4.68 ± 3.38 b	0.66	8.00 ~ 48.00	20.00 ± 6.84 b	0.33
处理 Treatment	茎粗/mm Stem diameter			下胚轴长/cm Hypocotyl length			SPAD
处理 Treatment	变幅 Range	均值 Average	变异系数 CV	变幅 Range	均值 Average	变异系数CV	变幅 Range	均值 Average	变异系数CV
正常磷 Normal P	2.62 ~ 6.27	4.19 ± 0.49 a	0.17	1.50 ~ 10.80	5.13 ± 2.06 a	0.40	21.30 ~ 46.90	36.74 ± 4.86 a	0.14
1%磷 1% P	2.18 ~ 4.78	3.53 ± 0.26 c	0.14	1.00 ~ 7.80	3.64 ± 1.63 b	0.35	23.70 ~ 51.60	36.74 ± 5.35 a	0.14
10%磷 10% P	2.10 ~ 6.50	3.76 ± 0.49 b	0.19	1.50 ~ 11.50	5.50 ± 1.82 a	0.35	23.80 ~ 51.90	36.67 ± 5.83 a	0.16
处理 Treatment	叶绿素含量/（mg · L^-1）Chlorophyll content
处理 Treatment	变幅 Range	均值 Average	变异系数CV
正常磷 Normal P	0.04 ~ 0.15	0.09 ± 0.00 a	0.22
1%磷 1% P	0.01 ~ 0.07	0.03 ± 0.00 b	0.33
10%磷 10% P	0.03 ~ 0.17	0.09 ± 0.00 a	0.33

指标 Index	1%磷主成分Principal component 1 2		权重 Weight	10%磷主成分Principal component 1 2		权重 Weight
鲜质量比值 Fresh weight ratio	0.940	0.171	21.148	0.901	0.055	19.596
株高比值 Plant height ratio	0.900	0.062	19.506	0.847	0.014	18.136
干质量比值 Dry weight ratio	0.856	0.061	18.565	0.817	-0.015	17.493
茎粗比值 Stem diameter ratio	0.854	-0.061	18.525	0.758	0.048	16.509
叶绿素含量比值Chlorophyll content ratio	-0.145	0.780	8.744	0.479	-0.267	12.298
SPAD比值SPAD ratio	0.277	0.514	9.621	0.118	0.777	8.661
下胚轴长度比值Hypocotyl length ratio	-0.027	-0.455	3.891	-0.095	0.667	7.306
特征值 Eigenvalue	3.285	1.089	—	3.022	1.126	—
方差贡献率 Variance contribution	46.489	16.005	—	43.175	16.080	—
累计贡献率 Cumulative percentage	46.489	62.495	—	43.175	59.256	—

指标 Index	1%磷主成分Principal component 1 2		权重 Weight	10%磷主成分Principal component 1 2		权重 Weight
鲜质量比值 Fresh weight ratio	0.940	0.171	21.148	0.901	0.055	19.596
株高比值 Plant height ratio	0.900	0.062	19.506	0.847	0.014	18.136
干质量比值 Dry weight ratio	0.856	0.061	18.565	0.817	-0.015	17.493
茎粗比值 Stem diameter ratio	0.854	-0.061	18.525	0.758	0.048	16.509
叶绿素含量比值Chlorophyll content ratio	-0.145	0.780	8.744	0.479	-0.267	12.298
SPAD比值SPAD ratio	0.277	0.514	9.621	0.118	0.777	8.661
下胚轴长度比值Hypocotyl length ratio	-0.027	-0.455	3.891	-0.095	0.667	7.306
特征值 Eigenvalue	3.285	1.089	—	3.022	1.126	—
方差贡献率 Variance contribution	46.489	16.005	—	43.175	16.080	—
累计贡献率 Cumulative percentage	46.489	62.495	—	43.175	59.256	—
