Fructokinase Gene PpyFRK5 Plays an Important Role in Sucrose Accumulation of Pear Fruit

doi:10.16420/j.issn.0513-353x.2021-0445

Acta Horticulturae Sinica ›› 2022, Vol. 49 ›› Issue (7): 1429-1440.doi: 10.16420/j.issn.0513-353x.2021-0445

• Research Papers • Previous Articles Next Articles

Fructokinase Gene PpyFRK5 Plays an Important Role in Sucrose Accumulation of Pear Fruit

TAO Xin¹, ZHU Rongxiang¹, GONG Xin¹, WU Lei¹, ZHANG Shaoling¹, ZHAO Jianrong²^,^*(), ZHANG Huping¹^,^*()

¹College of Horticulture,Nanjing Agricultural University,Nanjing 210095,China
²College of Resource and Environment,Anhui Science and Technology University,Fengyang,Anhui 233100,China

Received:2022-03-10 Revised:2022-04-20 Online:2022-07-25 Published:2022-07-29
Contact: ZHAO Jianrong,ZHANG Huping E-mail:zjr0105@163.com;hpzhang@njau.edu.cn

Abstract

Abstract:

As one of the important members of fructokinase gene family,the gene of PpyFRK5 was cloned utilizing‘Hosui’pear（Pyrus pyrifolia Nakai）fruit as the experimental material in the study. Simultaneously,its expression patterns and biological functions were studied. The results indicated that the protein encoded by PpyFRK5 belongs to the phosphofructokinase B subfamily（pfkB）,and contains the highly conserved pfkB characteristic domain and the ATP binding domain and sugar binding domain unique to fructokinase. The expression level of PpyFRK5 exhibited significant distinctions in different pear organs and fruit development stages,and reached the highest in fruits and seeds at the mature stage. PpyFRK5 was localized in the plasma membrane and cytoplasm. During the whole development of the pear fruit,there was a significant positive correlation between the expression level of PpyFRK5 and the sucrose content,and the sucrose content of pear fruits with transient overexpression of PpyFRK5 was significantly increased,while that of pear fruits with transient silencing of PpyFRK5 was significantly decreased;the promoter region of PpyFRK5 contained multiple cis-acting elements involved in light response,hormone induction,and stress response.

Key words: pear, fructokinase, expression pattern, gene function, sucrose accumulation

CLC Number:

S661.2

TAO Xin, ZHU Rongxiang, GONG Xin, WU Lei, ZHANG Shaoling, ZHAO Jianrong, ZHANG Huping. Fructokinase Gene PpyFRK5 Plays an Important Role in Sucrose Accumulation of Pear Fruit[J]. Acta Horticulturae Sinica, 2022, 49(7): 1429-1440.

Figures/Tables 10

References 31

[1]	Damari-Weissler H, Kandel-Kfir M, Gidoni D, Mett A, Belausov E, Granot D. 2006. Evidence for intracellular spatial separation of hexokinases and fructokinases in tomato plants. Planta, 224:1495-1502. pmid: 16977457
[2]	Damari-Weissler H, Rachamilevitch S, Aloni R, German M A, Cohen S, Zwieniecki M A, Holbrook N M, Granot D. 2009. LeFRK2 is required for phloem and xylem differentiation and the transport of both sugar and water. Planta, 230:795-805. doi: 10.1007/s00425-009-0985-4 pmid: 19633866
[3]	Davies H V, Shepherd L V, Burrell M M, Carrari F, Urbanczyk-Wochniak E, Leisse A, Hancock R D, Taylor M, Viola R, Ross H, McRae D, Willmitzer L, Fernie A R. 2005. Modulation of fructokinase activity of potato(Solanum tuberosum)results in substantial shifts in tuber metabolism. Plant Cell Physiol, 46:1103-1115. doi: 10.1093/pcp/pci123 URL
[4]	Dennis D, Blakeley S D. 2000. Carbohydrate metabolism//Buchanan B,Gruissem W,Jones R. Biochemistry and molecular biology of plants. American Society of Plant Physiologists, 46:630-675.
[5]	Fennington G J, Hughes T A. 1996. The fructokinase from Rhizobium leguminosarum biovar trifolii belongs to group I fructokinase enzymes and is encoded separately from other carbohydrate metabolism enzymes. Microbiology, 142:321-330. doi: 10.1099/13500872-142-2-321 URL
[6]	Fulda S, Mikkat S, Stegmann H, Horn R. 2011. Physiology and proteomics of drought stress acclimation in sunflower(Helianthus annuus L.). Plant Biol, 13:632-642. doi: 10.1111/j.1438-8677.2010.00426.x URL
[7]	Geng Yan-qiu, Dong Xiao-chang, Zhang Chun-mei. 2021. Recent progress of sugar transporter in horticultural crops. Acta Horticulturae Sinica, 48 (4):676-687.
	耿艳秋, 董肖昌, 张春梅. 2021. 园艺作物糖转运蛋白研究进展. 园艺学报, 48 (4):676-687.
[8]	German M A, Asher I, Petreikov M, Dai N, Schaffer A A, Granot D. 2004. Cloning,expression and characterization of LeFRK3,the fourth tomato (Lycopersicon esculentum Mill.)gene encoding fructokinase. Plant Sci, 166:285-291. doi: 10.1016/j.plantsci.2003.09.017 URL
[9]	German M A, Dai N, Chmelnitsky I, Sobolev I, Salts Y, Barg R, Schaffer A A, Granot D. 2002. LeFRK4,a novel tomato(Lycopersicon esculentum Mill.)fructokinase specifically expressed in stamens. Plant Sci, 163:607-613. doi: 10.1016/S0168-9452(02)00170-X URL
[10]	German M A, Dai N, Matsevitz T, Hanael R, Petreikov M, Bernstein N, Loffe M, Shahak Y, Schaffer A A, Granot D. 2003. Suppression of fructokinase encoded by LeFRK2 in tomato stem inhibits growth and causes wilting of young leaves. Plant J, 34:837-846. doi: 10.1046/j.1365-313X.2003.01765.x URL
[11]	Granot D, David-Schwartz R, Kelly G. 2013. Hexose kinases and their role in sugar-sensing and plant development. Front Plant Sci, 4:44. doi: 10.3389/fpls.2013.00044 pmid: 23487525
[12]	Livak K J, Schmittgen T D. 2001. Analysis of relative gene expression data using real-time quantitative PCR and the 2^-∆∆CT method. Methods, 25:402-408. doi: 10.1006/meth.2001.1262 pmid: 11846609
[13]	Lü J H, Tao X, Yao G H, Zhang S L, Zhang H P. 2020. Transcriptome analysis of low-and high-sucrose pear cultivars identifies key regulators of sucrose biosynthesis in fruits. Plant Cell Physiol, 61:1493-1506. doi: 10.1093/pcp/pcaa068 URL
[14]	Lü Jia-hong, Wang Ying-zhen, Cheng Rui, Wang Guo-ming, Zhang Shao-ling, Wu Jun, Zhang Hu-ping. 2018. Genome-wide identification and expression analysis of sucrose synthase(SUS)and sucrose phosphate synthase(SPS)gene families in pear. Acta Horticulturae Sinica, 45 (3):421-435.
	吕佳红, 王英珍, 程瑞, 王国明, 张绍铃, 吴俊, 张虎平. 2018. 梨蔗糖合成相关酶SUS和SPS基因家族的鉴定与表达分析. 园艺学报, 45 (3):421-435.
[15]	Martinez-Barajas E, Krohn B M, Stark D M, Randall D D. 1997. Purification and characterization of recombinant tomato fruit(Lycopersicon esculentum Mill.)fructokinase expressed in Escherichia coli. Protein Expres Purif, 11 (1):41-46. doi: 10.1006/prep.1997.0762 URL
[16]	Moriguchi T, Abe K, Sanada T, Yamaki S. 1992. Levels and role of sucrose synthase,sucrose-phosphate synthase,and acid invertase in sucrose accumulation in fruit of Asian pear. J Am Soc Hortic Sci, 117 (2):274-278.
[17]	Mukherjee T, Ivanova M, Dagda M, Kanayama Y, Granot D, Holaday A S. 2015. Constitutively overexpressing a tomato fructokinase gene(LeFRK1)in cotton(Gossypium hirsutum L. cv. Coker 312)positively affects plant vegetative growth,boll number and seed cotton yield. Funct Plant Biol, 42:899-908. doi: 10.1071/FP15035 pmid: 32480732
[18]	Odanaka S, Bennett A B, Kanayama Y. 2002. Distinct physiological roles of fructokinase isozymes revealed by gene-specific suppression of Frk1 and Frk2 expression in tomato. Plant Physiol, 129:1119-1126. pmid: 12114566
[19]	Pego J V, Smeekens S C. 2000. Plant fructokinases:a sweet family get-together. Trends Plant Sci, 5:531-536. pmid: 11120475
[20]	Riggs J W, Cavales P C, Chapiro S M, Callis J. 2017. Identification and biochemical characterization of the fructokinase gene family in Arabidopsis thaliana. BMC Plant Biol, 17:83-100. doi: 10.1186/s12870-017-1031-5 pmid: 28441933
[21]	Stein O, Avin-Wittenberg T, Krahnert I, Zemach H, Bogol V, Daron O, Aloni R, Fernie A R, Granot D. 2017. Arabidopsis fructokinases are important for seed oil accumulation and vascular development. Front Plant Sci, 7:2047-2062.
[22]	Stein O, Damari-Weissler H, Secchi F, Rachmilevitch S, German M A, Yeselson Y, Amir R, Schaffer A, Holbrook N M, Aloni R, Zwieniecki M A, Granot D. 2016. The tomato plastidic fructokinase SlFRK3 plays a role in xylem development. New Phytol, 209:1484-1495. doi: 10.1111/nph.13705 pmid: 26467542
[23]	Stein O, Granot D. 2018. Plant fructokinases:evolutionary,developmental,and metabolic aspects in sink tissues. Front Plant Sci, 9:339-350. doi: 10.3389/fpls.2018.00339 pmid: 29616058
[24]	Tanase K, Yamaki S. 2000. Sucrose synthase isozymes related to sucrose accumulation during fruit development of Japanese pear(Pyrus pyrifolia Nakai). J Jpn Soc Hortic Sci, 69:671-676. doi: 10.2503/jjshs.69.671 URL
[25]	Taylor M A, Ross H A, Gardner A, Davies H A. 1995. Characterisation of a cDNA encoding fructokinase from potato(Solanum tuberosum L.). J Plant Physiol, 145 (3):253-256. doi: 10.1016/S0176-1617(11)81885-7 URL
[26]	Yang J J, Zhu L C, Cui W F, Zhang C, Li D X, Ma B C, Cheng L L, Ruan Y L, Ma F W, Li M J. 2018. Increased activity of MdFRK2,a high-affinity fructokinase,leads to upregulation of sorbitol metabolism and downregulation of sucrose metabolism in apple leaves. Hortic Res, 5:71-82. doi: 10.1038/s41438-018-0099-x URL
[27]	Yao Gai-fang, Zhang Shao-ling, Cao Yu-fen, Liu Jun, Wu Jun, Yuan Jiang, Zhang Hu-ping, Xiao Chang-cheng. 2010. Characteristics of components and contents of soluble sugars in pear fruits from different species. Scientia Agricultura Sinica, 43 (20):4229-4237. (in Chinese)
	姚改芳, 张绍铃, 曹玉芬, 刘军, 吴俊, 袁江, 张虎平, 肖长城. 2010. 不同栽培种梨果实中可溶性糖组分及含量特征. 中国农业科学, 43 (20):4229-4237.
[28]	Yao Y, Geng M T, Wu X H, Sun C, Wang Y L, Chen X, Shang L, Lu X H, Li Z, Li R M, Fu S P, Duan R J, Liu J, Hu X W, Guo J C. 2017. Identification,expression,and functional analysis of the fructokinase gene family in Cassava. Int J Mol Sci, 18 (11):2398-2424. doi: 10.3390/ijms18112398 URL
[29]	Zhang H P, Su Y, Yu Q, Qin G H. 2021. Quantitative proteomic analysis of the pear(Pyrus pyrifolia cv.‘Hosui’)flesh provides novel insights about development and quality characteristics of fruit. Planta, 253:69. doi: 10.1007/s00425-021-03585-5 pmid: 33599839
[30]	Zhang H P, Wu J Y, Qin G H, Yao G F, Qi K J, Wang L F, Zhang S L. 2014a. The role of sucrose-metabolizing enzymes in pear fruit that differ in sucrose accumulation. Acta Physiol Plant, 36:71-77. doi: 10.1007/s11738-013-1387-6 URL
[31]	Zhang H P, Wu J Y, Tao S T, Wu T, Qi K J, Zhang S J, Wang J Z, Huang W J, Wu J, Zhang S L. 2014b. Evidence for apoplasmic phloem unloading in pear fruit. Plant Mol Biol Rep, 32:931-939. doi: 10.1007/s11105-013-0696-7 URL

用途 Use	名称 Name	序列（5′-3′） Sequence
实时荧光定量PCR	PpyFRK5-F	TTCGTTGGCAAGGTTGGAG
Quantitative real-time PCR	PpyFRK5-R	TCACCGTCGTTCTTCAAGGTC
	Tubulin-F	TGGGCTTTGCTCCTCTTAC
	Tubulin-R	CCTTCGTGCTCATCTTACC
基因克隆、超表达和亚细胞定位 Cloning,overexpression,and subcellular localization	35S:PpyFRK5-GFP-F	GAGAACACGGGGGACTCTAGAATGGCGAATTCAGAGAGTCCAC
	35S:PpyFRK5-GFP-R	GCCCTTGCTCACCATGGATCCTTTGGCTTTGGACTTGGAAATG
病毒诱导的基因沉默	pTRV2-PpyFRK5-F	GAAGGCCTCCATGGGGATCCTGTGGTTCTGTCCCTGTGG
Virus induced gene silencing	pTRV2-PpyFRK5-R	GCCTCGAGACGCGTGAGCTCCATCAGACTGGGTTGGAAGA
启动子扩增 Promoter amplification	PpyFRK5-pro-F	GTCGACGGTATCGATAAGCTTCCTTATATTTGTCGACTGTAGGTCGA
	PpyFRK5-pro-R	CGCTCTAGAACTAGTGGATCCTCTCTCTTAACTCTTGCGATTGAGA

用途 Use	名称 Name	序列（5′-3′） Sequence
实时荧光定量PCR	PpyFRK5-F	TTCGTTGGCAAGGTTGGAG
Quantitative real-time PCR	PpyFRK5-R	TCACCGTCGTTCTTCAAGGTC
	Tubulin-F	TGGGCTTTGCTCCTCTTAC
	Tubulin-R	CCTTCGTGCTCATCTTACC
基因克隆、超表达和亚细胞定位 Cloning,overexpression,and subcellular localization	35S:PpyFRK5-GFP-F	GAGAACACGGGGGACTCTAGAATGGCGAATTCAGAGAGTCCAC
	35S:PpyFRK5-GFP-R	GCCCTTGCTCACCATGGATCCTTTGGCTTTGGACTTGGAAATG
病毒诱导的基因沉默	pTRV2-PpyFRK5-F	GAAGGCCTCCATGGGGATCCTGTGGTTCTGTCCCTGTGG
Virus induced gene silencing	pTRV2-PpyFRK5-R	GCCTCGAGACGCGTGAGCTCCATCAGACTGGGTTGGAAGA
启动子扩增 Promoter amplification	PpyFRK5-pro-F	GTCGACGGTATCGATAAGCTTCCTTATATTTGTCGACTGTAGGTCGA
	PpyFRK5-pro-R	CGCTCTAGAACTAGTGGATCCTCTCTCTTAACTCTTGCGATTGAGA

顺式作用元件 cis-element	序列 Sequence	功能 Probable function
ABRE	ACGTG	脱落酸响应元件Involved in the abscisic acid response
ARE	AAACCA	厌氧诱导响应元件Essential for the anaerobic induction
AE-Box	ACAAACAA	光响应元件Part of a module for light response
CGTCA-motif	CGTCA	MeJA响应元件Involved in the MeJA response
Box-4	ATTAAT	光响应元件Involved in light response
CAAT-Box	CCAAT;CAAT	启动子和增强子区域元件Element in the promoter and enhancer regions
G-Box	CACGTT	光响应元件Involved in light response
LTR	CCGAAA	低温响应元件Involved in low-temperature response
MBS	CAACTG	MYB结合位点MYB binding site
TATA-Box	TATA;TATAAA	转录起始位点Approximately -30 from the transcription start
RY-element	CATGCATG	种子特异性调控响应元件Involved in seed-specific regulation
TC-rich repeats	ATTCTCTAAC	防御和胁迫响应元件Involved in defense and stress response
TCT-motif	TCTTAC	光响应元件Part of a light responsive element
TGACG-motif	TGACG	MeJA响应元件Involved in the MeJA response
as-1	TGACG	转录结合位点Transcription factor-binding site
circadian	CAAAGATATC	昼夜节律控制响应元件Involved in circadian control

顺式作用元件 cis-element	序列 Sequence	功能 Probable function
ABRE	ACGTG	脱落酸响应元件Involved in the abscisic acid response
ARE	AAACCA	厌氧诱导响应元件Essential for the anaerobic induction
AE-Box	ACAAACAA	光响应元件Part of a module for light response
CGTCA-motif	CGTCA	MeJA响应元件Involved in the MeJA response
Box-4	ATTAAT	光响应元件Involved in light response
CAAT-Box	CCAAT;CAAT	启动子和增强子区域元件Element in the promoter and enhancer regions
G-Box	CACGTT	光响应元件Involved in light response
LTR	CCGAAA	低温响应元件Involved in low-temperature response
MBS	CAACTG	MYB结合位点MYB binding site
TATA-Box	TATA;TATAAA	转录起始位点Approximately -30 from the transcription start
RY-element	CATGCATG	种子特异性调控响应元件Involved in seed-specific regulation
TC-rich repeats	ATTCTCTAAC	防御和胁迫响应元件Involved in defense and stress response
TCT-motif	TCTTAC	光响应元件Part of a light responsive element
TGACG-motif	TGACG	MeJA响应元件Involved in the MeJA response
as-1	TGACG	转录结合位点Transcription factor-binding site
circadian	CAAAGATATC	昼夜节律控制响应元件Involved in circadian control
