Efficient in vivo Induction of Tetraploids from Three Mono-Embryonic Citrus Cultivars

doi:10.16420/j.issn.0513-353x.2024-0974

Acta Horticulturae Sinica ›› 2025, Vol. 52 ›› Issue (9): 2291-2299.doi: 10.16420/j.issn.0513-353x.2024-0974

• Genetic & Breeding·Germplasm Resources·Molecular Biology • Next Articles

Efficient in vivo Induction of Tetraploids from Three Mono-Embryonic Citrus Cultivars

LU Xin¹, REN Jie¹, DUAN Yaoyuan¹, XIE Kaidong¹, XIAO Gong’ao¹, XIA Zewen¹, WANG Rong¹^,², WU Xiaomeng¹, GUO Wenwu¹^,^**()

¹ National Key Laboratory for Germplasm Innovation & Utilization of Horticultural Crops， Huazhong Agricultural University， Wuhan 430070， China
² College of Landscape & Horticulture， Yunnan Agricultural University， Kunming 650201， China

Received:2025-01-02 Revised:2025-03-03 Online:2025-09-25 Published:2025-09-24
Contact: GUO Wenwu

Abstract

Abstract:

Mono-embryonic tetraploid plants were produced from the seedlings of three mono-embryonic citrus cultivars（Orah mandarin，Xiangshui lemon and Juhuaxinyou pummelo）. After cutting off the epicotyls of seedlings，callus tissue was induced under dark and humid conditions for 9 d，then the callus tissue was treated with 0.025% colchicine solution for 2 h，and adventitious buds were induced to regenerate on the epicotyls under light. After growing to 3-4 real leaves，the regenerated plants were identified for ploidy and mono-embryony by using flow cytometry and InDel molecular marker analysis. The results showed that 8，21，and 9 mono-embryonic tetraploids plants of Orah mandarin，Xiangshui lemon，and Juhuaxinyou pummelo were obtained，with an average induction rate of 16.2%. The regenerated plants exhibited stable ploidy，with increased leaf thickness and enlarged stomata after chromosome doubling，while leaf shape index，density of oil gland and stomata decreased. This study produced valuable core mono-embryonic tetraploid germplasm resources as seed parents for seedless triploid breeding without immature embryo rescue via tissue culture in citrus.

Key words: citrus, mono-embryonic, tetraploid, colchicine, germplasm innovation

LU Xin, REN Jie, DUAN Yaoyuan, XIE Kaidong, XIAO Gong’ao, XIA Zewen, WANG Rong, WU Xiaomeng, GUO Wenwu. Efficient in vivo Induction of Tetraploids from Three Mono-Embryonic Citrus Cultivars[J]. Acta Horticulturae Sinica, 2025, 52(9): 2291-2299.

Figures/Tables 8

References 28

[1]	Aleza P, Juárez J, Cuenca J, Ollitrault P, Navarro L. 2012. Extensive citrus triploid hybrid production by 2x × 4x sexual hybridizations and parent-effect on the length of the juvenile phase. Plant Cell Reports,31:1723-1735.
[2]	Aleza P, Juárez J, Ollitrault P, Navarro L. 2009. Production of tetraploid plants of non apomictic citrus genotypes. Plant Cell Reports,28:1837-1846.
[3]	Allario T, Brumos J, Colmenero-Flores J M, Tadeo F, Froelicher Y, Talon M, Navarro L, Ollitrault P, Morillon R. 2011. Large changes in anatomy and physiology between diploid Rangpur lime(Citrus limonia)and its autotetraploid are not associated with large changes in leaf gene expression. Journal of Experimental Botany,62:2507-2519.
[4]	Barrett H C. 1974. Colchicine-induced polyploidy in citrus. Botanical Gazette,135:29-41.
[5]	Blasco M, Badenes M L, Naval M M. 2015. Colchicine-induced polyploidy in loquat[Eriobotrya japonica(Thunb.) Lindl.]. Plant Cell Tissue and Organ Cult, 120 (2):453-461.
[6]	Cheng Yunjiang. 2004. Somatic cell cytoplasmic inheritance and chloroplast simple sequence repeat(cpSSR)primer development in citrus[Ph. D. Dissertation]. Wuhan: Huazhong Agricultural University. (in Chinese)
	程运江. 2004. 柑橘体细胞胞质遗传及叶绿体SSR引物开发研究[博士论文]. 武汉: 华中农业大学.
[7]	Dang Jiangbo, Cui Lulu, Han Guohui, Li Cai, Xiang Suqiong, Guo Qigao, Liang Guolu. 2021. Ploidy manipulation and citrus breeding:current status,problems and prospects. Acta Horticulturae Sinica, 48 (4):791-810. (in Chinese) doi: 10.16420/j.issn.0513-353x.2020-0537
	党江波, 崔璐璐, 韩国辉, 李彩, 向素琼, 郭启高, 梁国鲁. 2021. 柑橘倍性操作技术与育种现状、难点及展望. 园艺学报, 48 (4):791-810. doi: 10.16420/j.issn.0513-353x.2020-0537
[8]	Deng Xiuxin. 2022. A review and perspective for citrus breeding in China during the last six decades. Acta Horticulturae Sinca, 49 (10):2063-2074. (in Chinese)
	邓秀新. 2022. 中国柑橘育种60年回顾与展望. 园艺学报, 49 (10):2063-2074. doi: 10.16420/j.issn.0513-353x.2021-0701
[9]	Eng W H, Ho W S. 2019. Polyploidization using colchicine in horticultural plants:a review. Scientia Horticulturae,246:604-617.
[10]	Ge Congcong, Wang Yana, Li Luanxiang, Zhang Yiqin, Yuan Xiaomai, Huang Guixiang. 2022. Phenotypic and genetic variation of hybrid progenies of Xiangshui lemon × Baihua lemon. Journal of Fruit Science, 39 (2):169-183. (in Chinese)
	葛聪聪, 王亚娜, 李鸾翔, 张艺琴, 袁小迈, 黄桂香. 2022. 香水柠檬 × 白花柠檬群体子代表型及遗传变异分析. 果树学报, 39 (2):169-183.
[11]	Grosser J W, Gmitter F G. 2011. Protoplast fusion for production of tetraploids and triploids:applications for scion and rootstock breeding in citrus. Plant Cell Tissue and Organ Cult,104:343-357.
[12]	Grosser J W, Kainth D, Dutt M. 2014. Production of colchicine-induced autotetraploids in pummelo(Citrus grandis Osbeck)through indirect organogenesis. HortScience,49:944-948.
[13]	Guo W W, Liang W J, Xie K D, Xia Q M, Fu J, Guo D Y, Xie Z Z, Wu X M, Yi H L, Deng X X. 2016. Exploitation of polyploids from 39 citrus seedling populations. Acta Horticulturae,1135:11-16.
[14]	Huang Qichun, Liu Jimin, He Xinhua, Huang Ke, Ran Zhilin, Wu Ronglun, Luo Jie, Li Chuying. 2014. Preliminary study on the cultivation performance of late maturing hybrid citrus‘Orah’in Wuming,Guangxi. South China Fruits, 43 (3):86-88. (in Chinese)
	黄其椿, 刘吉敏, 何新华, 黄克, 冉志林, 吴荣伦, 罗捷, 李初英. 2014. 晚熟杂柑“沃柑”在广西武鸣的栽培表现初报. 中国南方果树, 43 (3):86-88.
[15]	Jiang Hongen, Liu Mengjun. 2004. Studies on polyploid induction of Chinese jujube with colchicine. Acta Horticulturae Sinca, 31 (5):647-650. (in Chinese)
	蒋洪恩, 刘孟军. 2004. 秋水仙碱诱导枣多倍体的研究. 园艺学报, 31 (5):647-650.
[16]	Jiang Jingdong, Wei Zhuangmin, Wang Nan, Zhu Chenqiao, Ye Junli, Xie Zongzhou, Deng Xiuxin, Chai Lijun. 2023. Exploitation and identification of tetraploid resources of Hongkong Kumquat(Fortunella hindsii). Acta Horticulturae Sinica, 50 (1):27-35. (in Chinese) doi: 10.16420/j.issn.0513-353x.2021-0927
	蒋靖东, 韦壮敏, 王楠, 朱晨桥, 叶俊丽, 谢宗周, 邓秀新, 柴利军. 2023. 山金柑四倍体资源的发掘与鉴定. 园艺学报, 50 (1):27-35. doi: 10.16420/j.issn.0513-353x.2021-0927
[17]	Narukulla V, Lahane Y, Fiske K, Pandey S, Ziogas V. 2023. Induction of polyploidy in citrus rootstocks through in vitro colchicine treatment of seed-derived explants. Agronomy,13:1442.
[18]	Ren J, Lu X, Duan Y Y, Xiao G A, Xie K D, Wu X M, Guo W W. 2024. In vivo tetraploid induction of mono-embryonic citrus genotypes by colchicine treatment. Scientia Horticulturae,338:113701.
[19]	Shi Q H, Liu P, Liu M J, Wang J R, Xu J. 2015. A novel method for rapid in vivo induction of homogeneous polyploids via calluses in a woody fruit tree(Ziziphus jujuba Mill.). Plant Cell Tissue and Organ Cult,121:423-433.
[20]	Sun Zhichao, Cheng Hui, Guo Wenlei, Wang Honghong, Wang Zhengjia. 2015. Analysis of drought resistance of branch and leaf structure in Carya cathayensis. Journal of Fruit Science, 32 (4):633-640. (in Chinese)
	孙志超, 程慧, 郭文磊, 王红红, 王正加. 2015. 山核桃枝叶耐旱特性分析. 果树学报, 32 (4):633-640.
[21]	Wang X, Xu Y T, Zhang S Q, Cao L, Huang Y, Cheng J F, Wu G Z, Tian S L, Chen C L, Liu Y, Yu H W, Yang X M, Lan H, Wang N, Wang L, Xu J D, Jiang X L, Xie Z Z, Tan M L, Larkin R M, Chen L L, Ma B G, Ruan Y J, Deng X X, Xu Q. 2017. Genomic analyses of primitive,wild and cultivated citrus provide insights into asexual reproduction. Nature Genetics,49:765-772.
[22]	Xie K D, Yuan D Y, Wang W, Xia Q M, Wu X M, Chen C W, Chen C L, Grosser J W, Guo W W. 2019. Citrus triploid recovery based on 2x × 4x crosses via an optimized embryo rescue approach. Scientia Horticulturae,252:104-109.
[23]	Xie Shanpeng, Yang Wenhui, Chen Hao, Xiao Gongao, Xie Kaidong, Xia Qiangming, Wu Xiaomeng, Guo Wenwu. 2023. Production of nucellar seedlings and exploration of tetraploid from Satsuma mandarin Guoqing No. 1. Journal of Fruit Science, 40 (2):309-315. (in Chinese)
	谢善鹏, 杨雯惠, 陈昊, 肖公傲, 解凯东, 夏强明, 伍小萌, 郭文武. 2023. 国庆1号温州蜜柑珠心胚苗培育及四倍体发掘. 果树学报, 40 (2):309-315.
[24]	Zhang June. 2005. DNA content variation of calli,somatic embryogenesis and induction of autotetraploid in citrus[Ph. D. Dissertation]. Wuhan: Huazhong Agricultural University. (in Chinese)
	张俊娥. 2005. 柑橘愈伤组织DNA含量变异、体细胞胚胎发生及同源四倍体的诱导研究[博士论文]. 武汉: 华中农业大学.
[25]	Zhang Wen, Li Na, Li Dazhi, Yang Shuizhi, Qin Hualan, Qin Zhengyu, Qin Zhengyuan, Luo Sainan. 2022. Comprehensive evaluation in fruit quality of Juhuaxin pomelo. Hunan Agricultural Sciences,(4):53-56. (in Chinese)
	张文, 李娜, 李大志, 杨水芝, 覃华兰, 覃正玉, 覃正元, 罗赛男. 2022. 菊花芯柚果实品质综合评价. 湖南农业科学,(4):53-56.
[26]	Zhang Y Y, Zhang D M, Zhong Y, Chang X J, Hu M L, Cheng C Z. 2017. A simple and efficient in planta transformation method for pummelo (Citrus maxima)using Agrobacterium tumefaciens. Scientia Horticulturae,214:174-179.
[27]	Zhao Hongtao, Lu Zhen, Li Guoguo, Xie Kaidong, Zheng Jixiang, Liang Zeng, Liu Yaoxin, Ou Zhitao, Liang Chun, Wang Jubing, Zhou Shuangyun, Chen Dongkui, Chen Xiangling. 2024. Identification and evaluation of new mixoploid variants in Citrus reticulata‘Orah’. Journal of Fruit Science, 41 (7):1265-1274. (in Chinese)
	赵洪涛, 陆珍, 李果果, 解凯东, 郑吉祥, 梁增, 刘要鑫, 欧智涛, 梁春, 王举兵, 周双云, 陈东奎, 陈香玲. 2024. 沃柑混倍体新种质的鉴定及评价. 果树学报, 41 (7):1265-1274.
[28]	Zhou Rui, Xie Kaidong, Wang Wei, Peng Jun, Xie Shanpeng, Hu Yibo, Wu Xiaomeng, Guo Wenwu. 2020. Efficient identification of tetraploid plants from seedling populations of apomictic citrus genotypes based on morphological characteristics. Acta Horticulturae Sinica, 47 (12):2451-2458. (in Chinese) doi: 10.16420/j.issn.0513-353x.2020-0769
	周锐, 解凯东, 王伟, 彭珺, 谢善鹏, 胡益波, 伍小萌, 郭文武. 2020. 依据多倍体形态特征快速高效发掘柑橘四倍体. 园艺学报, 47 (12):2451-2458.

引物名称Primer name	引物序列（5′-3′）Primer sequence	参考文献Reference
mite_p1	F：GTACCGAATTACCMCCCATAA；R：GTAGGATTTGGGTTATTGATG	Wang et al.,2017
mite_p2	F：TCTGGTTCATTGAGAATCCGCG；R：ATCATGTGGGTCATGGTAC	Wang et al.,2017

引物名称Primer name	引物序列（5′-3′）Primer sequence	参考文献Reference
mite_p1	F：GTACCGAATTACCMCCCATAA；R：GTAGGATTTGGGTTATTGATG	Wang et al.,2017
mite_p2	F：TCTGGTTCATTGAGAATCCGCG；R：ATCATGTGGGTCATGGTAC	Wang et al.,2017

品种 Cultivar	诱导上胚轴数 Number of induced epicotyls	再生植株数 Number of regeneration	四倍体数 Number of tetraploids	混倍体数 Number of mixoploids	四倍体诱导/% Tetraploid induction rate	混倍体发生率/% Mixoploid incidence
沃柑Orah mandarin	115	55	18	8	32.7	14.5
香水柠檬Xiangshui lemon	271	233	32	16	13.7	6.9
菊花芯柚Juhuaxinyou pummelo	105	77	9	3	11.7	3.9
总计/平均Sum/Average	491	365	59	27	16.2	7.4

品种 Cultivar	诱导上胚轴数 Number of induced epicotyls	再生植株数 Number of regeneration	四倍体数 Number of tetraploids	混倍体数 Number of mixoploids	四倍体诱导/% Tetraploid induction rate	混倍体发生率/% Mixoploid incidence
沃柑Orah mandarin	115	55	18	8	32.7	14.5
香水柠檬Xiangshui lemon	271	233	32	16	13.7	6.9
菊花芯柚Juhuaxinyou pummelo	105	77	9	3	11.7	3.9
总计/平均Sum/Average	491	365	59	27	16.2	7.4

品种 Cultivar	初测4x数/株 Number of tetraploids identified in the first time	一年苗龄植株二次检测/株 Secondary ploidy identification			4x纯合率/% Tetraploid ratio
品种 Cultivar	初测4x数/株 Number of tetraploids identified in the first time	4x	2x	混倍体Mixoploid	4x纯合率/% Tetraploid ratio
沃柑Orah mandarin	8	8	0	0	100.0
香水柠檬Xiangshui lemon	32	24	3	5	75.0
菊花芯柚Juhuaxinyou pummelo	9	9	0	0	100.0
总计/平均 Sum/Average	49	41	9	7	83.7

Efficient in vivo Induction of Tetraploids from Three Mono-Embryonic Citrus Cultivars

RichHTML

PDF

Knowledge

Abstract

Cite this article

share this article

Figures/Tables 8

References 28

Related Articles 15

Recommended Articles

Metrics

Comments

品种 Cultivar	倍性 Ploidy	叶片厚度/mm Leaf thickness	叶形指数 Leaf shape index	油胞密度/ （个 · cm^-2） Oil gland density	气孔密度/ （个 · mm^-2） Stomatal density	气孔长轴长度/μm Long axis length of stomatal	气孔短轴长度/μm Short axis length of stomata
沃柑Orah mandarin	2x	0.27 ± 0.03	2.49 ± 0.18	102.1 ± 16.4	278.1 ± 23.0	22.0 ± 1.6	18.8 ± 1.0
沃柑Orah mandarin	4x	0.35 ± 0.02^**	2.28 ± 0.31	43.3 ± 16.0^**	165.2 ± 23.9^**	31.4 ± 2.3^**	26.0 ± 2.2^**
香水柠檬Xiangshui lemon	2x	0.27 ± 0.03	2.11 ± 0.20	98.9 ± 26.4	377.1 ± 69.6	21.4 ± 1.8	17.7 ± 1.8
香水柠檬Xiangshui lemon	4x	0.33 ± 0.02^**	1.81 ± 0.14^**	65.2 ± 14.3^**	275.7 ± 51.5^**	28.5 ± 2.1^**	22.9 ± 1.6^**
菊花芯柚Juhuaxinyou pummelo	2x	0.33 ± 0.03	2.17 ± 0.22	97.7 ± 20.5	333.6 ± 37.5	24.8 ± 1.6	18.7 ± 1.1
菊花芯柚Juhuaxinyou pummelo	4x	0.37 ± 0.05^*	1.81 ± 0.20^**	33.0 ± 14.2^**	224.8 ± 33.5^**	30.3 ± 2.7^**	22.6 ± 2.0^**
