Development of Species-Specific InDel Primers for Magnolia biondii and Their Application in Root Bark Identification

doi:10.16420/j.issn.0513-353x.2024-0563

Acta Horticulturae Sinica ›› 2025, Vol. 52 ›› Issue (9): 2387-2394.doi: 10.16420/j.issn.0513-353x.2024-0563

• Genetic & Breeding·Germplasm Resources·Molecular Biology • Previous Articles Next Articles

Development of Species-Specific InDel Primers for Magnolia biondii and Their Application in Root Bark Identification

DAI Xiaogang¹^,^*(), LIANG Qingqing¹, BI Changwei¹^,², WEI Mingchen¹, LIU Jingsheng¹

¹ College of Forestry and Grassland， Co-Innovation Center for Sustainable Forestry in Southern China，Key Laboratory of Tree Genetics and Biotechnology of Educational Department of China，State Key Laboratory of Tree Genetics and Breeding，Nanjing Forestry University， Nanjing 210037， China
² College of Information Science and Technology & Artificial Intelligence， Nanjing 210037， China

Received:2025-05-16 Revised:2025-06-23 Online:2025-09-25 Published:2025-09-24
Contact: DAI Xiaogang

Abstract

Abstract:

As raw materials for extracting parthenolide，the root barks of Magnolia biondii may be adulterated with that of M. denudata. Using these two species as research materials，species-specific InDel markers were identified based on pooled sequencing data. The filtered pooled sequencing data yieled 103.6 and 82.4 Gb of high-quality sequences for M. biondii and M. denudata，respectively. After alignment the filtered reads to the genome of M. biondii，a total of 13 152 interspecific-fixed InDel sites（≥ 5 bp）were detected，and primers were successfully designed for 10 627 of the identified InDels. Two pairs of primers were randomly selected from each of the 19 chromosomes of M. biondii for synthesis. Amplification results showed that 31 primer pairs（81.6%）exhibited universality in M. denudata，with 17 primer pairs displaying length polymorphism between the two species. Further examination by capillary electrophoresis using natural populations of M. biondii and M. denudata revealed that primers Mbi010 and Mbi069 produced species-specific bands with intraspecific conservation and marked interspecific differences. Primer Mbi010 could amplify 120 bp and 115 bp fragments in M. biondii and M. denudata，respectively，while Mbi069 generated 146 bp and 140 bp fragments in respective species. Using these two primer pairs to amplify DNA extracted from mixed root bark samples of M. biondii and M. denudata successfully identified species-specific fragments for each taxon，demonstrating their utility for authenticating of M. biondii root bark adulteration.

Key words: Magnolia biondii, Pool-seq, species-specific primers, root bark, molecular identification

DAI Xiaogang, LIANG Qingqing, BI Changwei, WEI Mingchen, LIU Jingsheng. Development of Species-Specific InDel Primers for Magnolia biondii and Their Application in Root Bark Identification[J]. Acta Horticulturae Sinica, 2025, 52(9): 2387-2394.

Figures/Tables 5

References 20

[1]	Bolger A M, Marc L, Bjoern U. 2014. Trimmomatic:a flexible trimmer for illumina sequence data. Bioinformatics,(15):2114-2120.
[2]	Dai Xiaogang, Chen Chen, Xue Liangjiao, Wu Huaitong, Yin Tongming. 2021. Identification of interspecific hybrids between Populus deltoides and P. simonii by using species-specific InDel marker. Scientia Silvae Sinicae, 57 (11):79-84. (in Chinese)
	戴晓港, 陈晨, 薛良交, 吴怀通, 尹佟明. 2021. 基于物种特异性 InDel 标记鉴别美洲黑杨与小叶杨的杂交子代. 林业科学, 57 (11):79-84.
[3]	Dai Xiaogang, Han Qiaozi, Yin Tongming. 2024. Species-specific Indel markers in five species from different poplar sects and their application in identification of inter-specific hybrids. Scientia Silvae Sinicae, 60 (2):78-86. (in Chinese)
	戴晓港, 韩峭子, 尹佟明. 2024. 杨属派间5个种特异性InDel引物及在派间杂交子代鉴别中的应用. 林业科学, 60 (2):78-86.
[4]	Dong S, Liu M, Liu Y, Chen F, Yang T, Chen L, Zhang X, Guo X, Fang D, Li L, Deng T. 2021. The genome of Magnolia biondii pamp. provides insights into the evolution of magnoliales and biosynthesis of terpenoids. Horticulture Research,8:38.
[5]	Gao Baoyun, Zhao Yuemei. 2018. Identification of Magnolia denudata and its relative species based on ITS sequences. Acta Agriculturae Jiangxi, 30 (5):85-88,93. (in Chinese)
	高宝云, 赵月梅. 2018. 基于ITS序列对辛夷及其混伪品种的鉴别. 江西农业学报, 30 (5):85-88,93.
[6]	Garrison E, Marth G. 2012. Haplotype-based variant detection from short-read sequencing. Biology, Computer Science arXiv:Genomics,1207.3907.
[7]	Jiang Shuang, Wang Xiaoqing, Shi Chunhui, Li Shuigen, Luo Jun. 2024. Detection of SLAF tag polymorphism associated with pear russet peel by PCR product pool resequencing. Acta Horticulturae Sinica, 51 (4):707-714. (in Chinese) doi: 10.16420/j.issn.0513-353x.2023-0263
	蒋爽, 王晓庆, 施春晖, 李水根, 骆军. 2024. 利用PCR产物混池重测序检测梨褐皮关联SLAF标签多态性. 园艺学报, 51 (4):707-714.
[8]	Li Chengtao, Li Li, Hou Yiping, Zhang Suhua, Liu Yacheng, Sun Hongyu. 2016. Technical standard of paternity identification. Ministry of Justice of the People’s Republic of China,SF/Z JD0105001-2016. (in Chinese)
	李成涛, 李莉, 侯一平, 张素华, 刘雅诚, 孙宏钰. 2016. 亲权鉴定技术规范. 中华人民共和国司法部,SF/Z JD0105001-2016.
[9]	Li H, Durbin R. 2010. Fast and accurate long-read alignment with Burrows-Wheeler transform. Bioinformatics, 26 (5):589-595. doi: 10.1093/bioinformatics/btp698 pmid: 20080505
[10]	Li H, Handsaker B, Wysoker A, Fennell T, Ruan J, Homer N, Marth G, Abecasis G, Durbin R. 2009. The sequence alignment/map format and SAMtools 1000 genome project data processing subgroup. Bioinformatics, 25 (16):2078-2079. doi: 10.1093/bioinformatics/btp352 pmid: 19505943
[11]	Li Q, Sun Y, Liu B, Li J, Hao X, Ge W, Zhang X, Bao S, Gong J, Jiang Z, Qiu C, Zhao L, Zhao Y, Chen Y, Yang X, Ding Y, Wu Z. 2020. ACT 001 modulates the NF-κB/MnSOD/ROS axis by targeting IKKβ to inhibit glioblastoma cell growth. J Mol Med(Berl), 98 (2):263-277.
[12]	Liu Jingsheng, Tang Xinwei, Zhou Hu, Chen Lei, Dai Xiaogang, Yin Tongming. 2024. Dynamic content changes of parthenolide from four Maganolia species. Journal of Nanjing Forestry University(Natural Sciences Edition), 48 (2):227-233. (in Chinese)
	刘景胜, 唐鑫伟, 周虎, 陈雷, 戴晓港, 尹佟明. 2024. 4种玉兰的小白菊内酯含量的变化动态研究. 南京林业大学学报(自然科学版), 48 (2):227-233. doi: 10.12302/j.issn.1000-2006.202210036
[13]	Majdi M, Liu Q, Karimzadeh G, Malboobi M A, Beekwilder J, Cankar K, Vos Rd, Todorović S, Simonović A, Bouwmeester H. 2011. Biosynthesis and localization of parthenolide in glandular trichomes of feverfew(Tanacetum parthenium L. Schulz Bip.). Phytochemistry,72:1739-1750.
[14]	Shi Shengming, Pan Mingjia, Wang Jie, Chen Changqing. 2016. Application of molecular identification techniques in Chinese materia medica. Chinese Traditional and Herbal Drugs, 47 (17):3121-3126. (in Chinese)
	时圣明, 潘明佳, 王洁, 陈常青. 2016. 分子鉴定技术在中药中的应用. 中草药, 47 (17):3121-3126.
[15]	Shi Y H, Bai G Y, Wang P, Cai D P, Chen Y, Wang P. 2021. A phase I dose-escalation study to evaluate pharmacokinetics,safety and tolerability of ACT 001 in patients with advanced glioma. Journal of Clinical Oncology, 39 (15):2044.
[16]	Untergasser A, Cutcutache I, Koressaar T, Ye J, Faircloth B C, Remm M, Rozen S G. 2012. Primer3--new capabilities and interfaces. Nucleic Acids Research, 40 (15):e115.
[17]	Xu Y, Li Z. 2022. Bulk segregation analysis in the NGS era:a review of its teenage years. The Plant Journal, 109 (6):1355-1374.
[18]	Zhang Honglian, Li Huogen, Xu Meng, Feng Yuanheng. 2010. Identification of Liriodendron tulipifera,Liriodendron chinense and hybrid Liriodendron using species-specific SSR Markers. Scientia Silvae Sinicae, 46 (1):36-39. (in Chinese)
	张红莲, 李火根, 胥猛, 冯源恒. 2010. 鹅掌楸属种及杂种的SSR分子鉴定. 林业科学, 46 (1):36-39.
[19]	Zhang Xinyi, Qiu Yuxuan, Hu Yang, Tian Rong, Zhao Mian, Yan Hui, Wang Xiazhang, Hu Lihong. 2023. Molecular identification of Magnoliae flos and its relatives based on DNA barcoding. Journal of Nanjing University of Traditional Chinese Medicine, 39 (11):1086-1093. (in Chinese)
	张心怡, 邱雨轩, 胡杨, 田荣, 赵勉, 严辉, 王吓长, 胡立宏. 2023. 中药辛夷及其近缘种的DNA条形码分子鉴定. 南京中医药大学学报, 39 (11):1086-1093.
[20]	Zhou Qian, Qiao Siwei, Yin Min, Tian Mei, Wang Qizhi, Tong Haiying, Xu Shu, Feng Xi. 2022. Comparison on contents of parthenolide in leaves of eight Magnoliaceae species and twenty-three Asteraceae species. Journal of Plant Resources and Enviroment, 31 (2):85-87. (in Chinese)
	周倩, 乔思薇, 印敏, 田梅, 王奇志, 佟海英, 徐曙, 冯煦. 2022. 木兰科8种植物和菊科23种植物叶片中小白菊内酯含量比较. 植物资源与环境学报, 31 (2):85-87.

样品 Sample	原始测序序列 Raw read	过滤后序列 Clean read	高质量序列比例/% Clean reads rate	高质量碱基数量/Gb Clean read base	Q30/%	GC含量/% GC content
望春玉兰 Magnolia biondii	709 647 064	690 949 980	97.39	103.6	93.92	36.17
玉兰 Magnolia denudata	560 966 106	549 298 162	97.92	82.4	93.96	36.32

样品 Sample	原始测序序列 Raw read	过滤后序列 Clean read	高质量序列比例/% Clean reads rate	高质量碱基数量/Gb Clean read base	Q30/%	GC含量/% GC content
望春玉兰 Magnolia biondii	709 647 064	690 949 980	97.39	103.6	93.92	36.17
玉兰 Magnolia denudata	560 966 106	549 298 162	97.92	82.4	93.96	36.32

序号 Seq.	染色体 Chr.	引物名称 Primer name	上游引物（5′-3′） Forward primer	下游引物（5′-3′） Reverse primer	片段大小/bp Fragment size	退火温度/℃ T_m
1	Chr01	Mbi002	TCACTTGATTTGACCGTTGA	ATCTGATGTCGCCGCAAG	104	57.6
2	Chr01	Mbi010	TTCAATCATCCCATTAGCTGC	GGGACCTTCATCCAAATCAA	123	60.0
3	Chr02	Mbi022	CAACGGTCGGAATTCAATCT	GCTCGACTCATAAACAGCCC	150	59.9
4	Chr02	Mbi030	CTCACCTCCATTACCCTCCA	TGGACTGGTTTGATGCGATA	137	59.9
5	Chr03	Mbi031	GCCCCAAAGATCTTAACCAG	TAAAGAGGCTGTTTGGTGCC	108	58.6
6	Chr03	Mbi032	CGGCCAGACAATCTAGGAAG	GGGCATCAAATCACAACCTT	109	59.8
7	Chr04	Mbi034	CTGGCCTCTTTCTTTGGAAG	TGGCTCACACAAAGCAAGTT	133	59.0
8	Chr04	Mbi037	GGATGGACGGTGTGGATAAG	ATGATGAGCAAGGCCAGAAT	101	60.1
9	Chr05	Mbi068	GACTATAAAGGCGCGTCAGC	GCCAGCTTCAAAACGTATGC	129	60.0
10	Chr05	Mbi069	GCATTTGGTTCGGCTGTAGT	TGGTGCTGTGGGTGTAAGTC	147	60.1
11	Chr06	Mbi076	CTTTTGGTTACTGGGCCATC	GGCCTCGAGTCGTACCATAG	133	59.4
12	Chr06	Mbi082	ACAAACGCCTACCGTTGAAA	CCAAAGTTTTCGATCAGGCT	127	60.5
13	Chr07	Mbi094	GCATTCCAAGAAAGAATGCC	TCCTCCCTTGTCATCAGCAT	101	59.6
14	Chr07	Mbi106	CAGCCTCATCCATGTGTGTT	GACCAAATTCCACATCTCGG	138	59.5
15	Chr08	Mbi114	GGGTTGCAATAGGACTGAGC	CTGCAGAAGTTGGTCCTGCT	138	59.7
16	Chr08	Mbi115	AGCCATGGGGAAAAATTCAT	CTAATCAATCCATGCTGGGG	137	60.5
17	Chr09	Mbi116	GGCTCAGTTTCTCCTTACCG	ACCCACCATCCTCTTCCTCT	107	58.9
18	Chr09	Mbi117	ACACAAATGCCCATACATGC	GTGTGGCCCACCAAATAAAC	110	59.2
19	Chr10	Mbi121	CCATTAAGACGGTTCGGCTA	CGGACTTCTCGTTTCCAAAA	149	60.0
20	Chr10	Mbi123	TAGGGCCACTGAAATGGAAG	GTTTCCAACAGGATTGCACC	142	60.0
21	Chr11	Mbi134	TCCAAATGTGTGGAGGATAGC	TTATTCCAGTGATGCAGTAGCA	146	59.9
22	Chr11	Mbi137	GTTGGTACCTAGCAGACCGC	TGGGACCCTATGAAGCTTTT	149	59.7
23	Chr12	Mbi141	TCTTTTCTATCGGTGCGTCC	GCAAGCAAGATTCAACCCAT	107	60.2
24	Chr12	Mbi142	AACCTAAACCCGATCCTGAAA	AGGTTATAGGTTATAGGTTTGGGAA	100	59.8
25	Chr13	Mbi144	ACTTTCGCTTCCCTCACCTT	TAATGGGCAATCACTTGTGG	140	60.2
26	Chr13	Mbi153	AACGGTCCAACCATCTCAAG	CCTCCACGTGTGGTCTACCT	132	59.9
27	Chr14	Mbi154	AGCATGTGGTGTTCAGTGGA	CCCTACAAAACACCGTAGGAA	149	60.1
28	Chr14	Mbi159	TCCTAAATGGTGAAAAGCAAA	TCAGAGAGGAACCTTGTGGC	126	57.4
29	Chr15	Mbi164	GAGATCCAGGCCATCAAATG	GATCAGGTGGGGTCCTCTTT	108	60.4
30	Chr15	Mbi169	TCTGAGCTTTCCACTCGTGA	CCAGCCATTGATTTGTTTTG	114	59.7
31	Chr16	Mbi184	GGCCATTCTACTCCGAACTG	GGGGTGGTTATGAGTTCTGC	137	59.6
32	Chr16	Mbi195	GATTCGACCGCTGGAGTTAC	TCTCCTAGAGGATGGCCAAA	124	59.7
33	Chr17	Mbi196	GGCGAGCATGACTCAATATG	AGGGGGTTTTATGAGTCGCT	130	59.2
34	Chr17	Mbi202	TTGTATTTGGCCGGATCAAC	CATCTTGGGTTGTTAGTTGGG	146	60.7
35	Chr18	Mbi204	ACCACTGTTGTTTGGGCTGT	TTGAAGCTGGTGGAACTGTG	132	60.4
36	Chr18	Mbi210	ACCAGGACCACACCTTTCAG	CACGTGTCGAAACGCTACTC	129	60.0
37	Chr19	Mbi216	GGCTACATGAGACTCGACCC	TGTGCACTGCTTAGCAAATTC	118	59.6
38	Chr19	Mbi218	GAAAACTTCCTAGGGCCCAC	CTAATTGAACGGCCACCATT	141	59.9

序号 Seq.	染色体 Chr.	引物名称 Primer name	上游引物（5′-3′） Forward primer	下游引物（5′-3′） Reverse primer	片段大小/bp Fragment size	退火温度/℃ T_m
1	Chr01	Mbi002	TCACTTGATTTGACCGTTGA	ATCTGATGTCGCCGCAAG	104	57.6
2	Chr01	Mbi010	TTCAATCATCCCATTAGCTGC	GGGACCTTCATCCAAATCAA	123	60.0
3	Chr02	Mbi022	CAACGGTCGGAATTCAATCT	GCTCGACTCATAAACAGCCC	150	59.9
4	Chr02	Mbi030	CTCACCTCCATTACCCTCCA	TGGACTGGTTTGATGCGATA	137	59.9
5	Chr03	Mbi031	GCCCCAAAGATCTTAACCAG	TAAAGAGGCTGTTTGGTGCC	108	58.6
6	Chr03	Mbi032	CGGCCAGACAATCTAGGAAG	GGGCATCAAATCACAACCTT	109	59.8
7	Chr04	Mbi034	CTGGCCTCTTTCTTTGGAAG	TGGCTCACACAAAGCAAGTT	133	59.0
8	Chr04	Mbi037	GGATGGACGGTGTGGATAAG	ATGATGAGCAAGGCCAGAAT	101	60.1
9	Chr05	Mbi068	GACTATAAAGGCGCGTCAGC	GCCAGCTTCAAAACGTATGC	129	60.0
10	Chr05	Mbi069	GCATTTGGTTCGGCTGTAGT	TGGTGCTGTGGGTGTAAGTC	147	60.1
11	Chr06	Mbi076	CTTTTGGTTACTGGGCCATC	GGCCTCGAGTCGTACCATAG	133	59.4
12	Chr06	Mbi082	ACAAACGCCTACCGTTGAAA	CCAAAGTTTTCGATCAGGCT	127	60.5
13	Chr07	Mbi094	GCATTCCAAGAAAGAATGCC	TCCTCCCTTGTCATCAGCAT	101	59.6
14	Chr07	Mbi106	CAGCCTCATCCATGTGTGTT	GACCAAATTCCACATCTCGG	138	59.5
15	Chr08	Mbi114	GGGTTGCAATAGGACTGAGC	CTGCAGAAGTTGGTCCTGCT	138	59.7
16	Chr08	Mbi115	AGCCATGGGGAAAAATTCAT	CTAATCAATCCATGCTGGGG	137	60.5
17	Chr09	Mbi116	GGCTCAGTTTCTCCTTACCG	ACCCACCATCCTCTTCCTCT	107	58.9
18	Chr09	Mbi117	ACACAAATGCCCATACATGC	GTGTGGCCCACCAAATAAAC	110	59.2
19	Chr10	Mbi121	CCATTAAGACGGTTCGGCTA	CGGACTTCTCGTTTCCAAAA	149	60.0
20	Chr10	Mbi123	TAGGGCCACTGAAATGGAAG	GTTTCCAACAGGATTGCACC	142	60.0
21	Chr11	Mbi134	TCCAAATGTGTGGAGGATAGC	TTATTCCAGTGATGCAGTAGCA	146	59.9
22	Chr11	Mbi137	GTTGGTACCTAGCAGACCGC	TGGGACCCTATGAAGCTTTT	149	59.7
23	Chr12	Mbi141	TCTTTTCTATCGGTGCGTCC	GCAAGCAAGATTCAACCCAT	107	60.2
24	Chr12	Mbi142	AACCTAAACCCGATCCTGAAA	AGGTTATAGGTTATAGGTTTGGGAA	100	59.8
25	Chr13	Mbi144	ACTTTCGCTTCCCTCACCTT	TAATGGGCAATCACTTGTGG	140	60.2
26	Chr13	Mbi153	AACGGTCCAACCATCTCAAG	CCTCCACGTGTGGTCTACCT	132	59.9
27	Chr14	Mbi154	AGCATGTGGTGTTCAGTGGA	CCCTACAAAACACCGTAGGAA	149	60.1
28	Chr14	Mbi159	TCCTAAATGGTGAAAAGCAAA	TCAGAGAGGAACCTTGTGGC	126	57.4
29	Chr15	Mbi164	GAGATCCAGGCCATCAAATG	GATCAGGTGGGGTCCTCTTT	108	60.4
30	Chr15	Mbi169	TCTGAGCTTTCCACTCGTGA	CCAGCCATTGATTTGTTTTG	114	59.7
31	Chr16	Mbi184	GGCCATTCTACTCCGAACTG	GGGGTGGTTATGAGTTCTGC	137	59.6
32	Chr16	Mbi195	GATTCGACCGCTGGAGTTAC	TCTCCTAGAGGATGGCCAAA	124	59.7
33	Chr17	Mbi196	GGCGAGCATGACTCAATATG	AGGGGGTTTTATGAGTCGCT	130	59.2
34	Chr17	Mbi202	TTGTATTTGGCCGGATCAAC	CATCTTGGGTTGTTAGTTGGG	146	60.7
35	Chr18	Mbi204	ACCACTGTTGTTTGGGCTGT	TTGAAGCTGGTGGAACTGTG	132	60.4
36	Chr18	Mbi210	ACCAGGACCACACCTTTCAG	CACGTGTCGAAACGCTACTC	129	60.0
37	Chr19	Mbi216	GGCTACATGAGACTCGACCC	TGTGCACTGCTTAGCAAATTC	118	59.6
38	Chr19	Mbi218	GAAAACTTCCTAGGGCCCAC	CTAATTGAACGGCCACCATT	141	59.9
